The Michelin XLEZ 11R22.5 LRH 16PL is a SmartWay-verified low-rolling-resistance radial steer tire designed for long-haul and regional commercial trucks, featuring 16-ply tubeless construction, a 19/32-inch tread depth, L speed rating (up to 75 mph), 41.3-inch overall diameter, 11.2-inch section width, 144 load index with a maximum single load of 6610 lbs at 120 psi, and patented dual-compound technology for 5% improved rolling resistance over its predecessors.
Key Features & Benefits
Fuel Efficiency — Dual‑compound tread: one layer designed for high mileage, another for cool-running durability, which helps reduce rolling resistance.
Long Casing Life / Retreadability — Full-width elastic protector ply and a durable inner liner help protect against wear and damage, boosting retread potential.
Even Wear — Directional miniature sipes and decoupling grooves help dissipate stress and reduce irregular wear.
Low Heat Build-up — Cool-running compound in the lower tread layer helps maintain casing strength over time. Eco & Efficiency Certified — Approved for SmartWay, contributing to lower emissions and better fuel efficiency. Spec Chart — Michelin XLEZ / X Line Energy Z 11R22.5 LRH (16‑Ply)
Property | Specification |
|---|---|
Product / Model | Michelin X Line Energy Z (11R22.5) |
Ply / Load Range | 16‑ply, Load Range H |
Load Index | 146 / 143 (Single / Dual) |
Speed Rating | L (75 mph / ~121 km/h) |
Maximum Inflation Pressure | 120 psi |
Overall Diameter | ~ 41.3 in / 1,048 mm |
Tread Depth | 19 / 32nds (≈ 15.1 mm) |
Approved / Measured Rim Width | 7.50″ – 8.25″ |
Maximum Load (Single) | 6,175 lb / 2,800 kg (for the 11R22.5 “Z” version) |
Loaded Radius | 489.2 mm / 19.3 in |
Seat Diameter | 22.5 in |
Sidewall Type | Black Sidewall (BSW) |
